Godson – 3 Rolls double pinch type plate bending machine is designed for bending light, medium & Heavy gauge plate with double pinch and pre-bending operation. This one incorporates a fixed top roll and two independent adjustable bottom rolls. This Machine is able to do symmetrical & asymmetrical Bending works, moreover since it's a double pinch machine which controls two edges pre-bending with one inscrtions of steel plate in the machine. For pre-bending is the way to reduce the flat end of minimum on the both two edges. This is accomplished by clamping the steel plate by Top and one Bottom roll and bending the clamped portion by another bottom roll to the desired radius. Machine is most suitable for accurate bending works. The machine has inherent capacity for conical bending, Section bending can be possible with extra attachment.

The machine is supplied with three power roll, In mechanical Version the two bottom rolls are lifted individually by individual Gear Box & Electric Brake Motor, the same operation is carried out by Hydraulic Power Pack Unit & Individual Hydraulic cylinders in Hydro-Mechanical version.

The top & bottom roll are power individual Special designed gear box & Motor.
